Sub250 Oasisfly35 DC O4 Pro Digital HD Freestyle Quadcopter FPV Drone GPS ELRS

OasisFly35 – Max compatible with O4 Pro HD VTX. DC frame + 1804 motors deliver strong thrust and clean, wide visuals. Redfox A3 45A AIO ensures fast response and high efficiency. GPS included for reliable RTH in any environment.

Feature

1. Compatible with Analog / O3 / O4 Pro, switch freely between scenarios to meet varied creative needs.

2. DC frame design delivers clean visuals and heightened flight immersion.

3. 1804 3450KV motors + 45A AIO ESC ensure fast response for all flight maneuvers.

4. Integrated side-plate structure combines aerodynamics and durability, protecting core components for impact-resistant flights.

5. GPS standard across all models enables confident flying and RTH, handling complex environments with ease.

Model: OasisFly35 DC O4 Pro Version

• Wheelbase: 175mm

• Arm Thickness: 3.5mm

• Bottom Plate: 1.5mm

• Mid Plate: 2.5mm

• Top Plate: 2.0 mm

• Motor Mounting Pattern: 9*9mm / 12*12mm

• VTX: DJI O4 Pro

• Motor: 1804  3450KV

• FC: RedFox A3 45A AIO

• ESC Firmware: BLHeli_32

• MCU： STM32F722

• IMU：ICM42688-P

• Propeller: HQ 3.5*3.5*3

• Receiver: ELRS/PNP

• GPS: SUB-M10

• Recommended Battery: 4S 530mAh

• Power Connector: XT30

• Body Weight: 194g

• Takeoff Weight: 245g (with 4S 530mAh battery)

• Max Flight Time: 5min 20s

• FC Firmware & Betaflight_4.5.2-SUB250REDFOXF722AIO

O4 PRO Version – Product List (Not Including batteries)

• 1 × GPS Setup Manual

• 1 × Sub250 RedFox A3 AIO Manual

• 1 × Sub250 Rear Silicone Strap with Zinc-Alloy Buckle (11×170 mm)

• 1 × HQ T3.5×3.5×3 Propellers (2 CW + 2 CCW)

• 1 × Sub250 Redfox A3 AIO USB-C Adapter Board

• 1 × 45 mm Dual-End SH1.0-5P Cable

• 1 × Sub250 Merchandise Sticker

• 1 × Sub250 Drone Series Sticker

• 1 × Battery Anti-Slip Pad

• 1 × Sub250 OasisFly35 Lens Silicone Pad (50°)

• 1 × Landing Gear Vibration-Damping Pad (Pack)

• 1 × L-Shaped Hex Wrench (1.5 mm)

• 2 × M2×4×22 Aluminum Textured Standoff (Black)

• 1 × Spare Screw Pack

• 1 × OasisFly35 DC Analog Camera Mount (3D Print)

• 1 × Right Side Plate (Large)

• 1 × Left Side Plate (Large)

• 1 × Right Rear Side Plate

• 1 × Left Rear Side Plate

• 4 x TPU Landing Pads
